Model : Hgr-34
Dimension : 610x700x920mm
Heat Flux : 16kw/H
Net Weight : 85kgs
Gross Weight : 90kgs
Bruner : 8
Gas stove, gas range, cooking range
1. Durable stainless steel construction.
2. Easy to clean, hygienic body, ergonomically design.
3. Unit enables to obtain the maximum efficiency with minimum energy consumption.
4. Heavy duty cast iron.
6. Designed for using large stockpots.
7. High efficiency casting iron, gas burners and high quality gas valves provides power and safety.
8. With big size garbage collection plate.
Model: HGR-38
Name: 8-burner stove
Dimension: 1100x700x920mm
Heat Flux: 32kw/h
Model: HGR-902
Name: 2-burner gas range with gas griddle
Dimension: 800x900x410mm
Heat Flux: 12kw/h
Model: HGR-6
Name: 6-burner gas range
Dimension: 1200x900x350mm
Heat Flux: 24kw/h
Model: HGR-22
Name: 2-burner heavy duty gas range
Dimension: 310x770x420mm
Heat Flux: 8kw/h
Feature of HGR-22 gas range
1. With electronic ignition.
2. Equip with flame failure device.
Model : Hgr-34
Dimension : 610x700x920mm
Heat Flux : 16kw/H
Net Weight : 85kgs
Gross Weight : 90kgs
Bruner : 8
Gas stove, gas range, cooking range
1. Durable stainless steel construction.
2. Easy to clean, hygienic body, ergonomically design.
3. Unit enables to obtain the maximum efficiency with minimum energy consumption.
4. Heavy duty cast iron.
6. Designed for using large stockpots.
7. High efficiency casting iron, gas burners and high quality gas valves provides power and safety.
8. With big size garbage collection plate.
Model: HGR-38
Name: 8-burner stove
Dimension: 1100x700x920mm
Heat Flux: 32kw/h
Model: HGR-902
Name: 2-burner gas range with gas griddle
Dimension: 800x900x410mm
Heat Flux: 12kw/h
Model: HGR-6
Name: 6-burner gas range
Dimension: 1200x900x350mm
Heat Flux: 24kw/h
Model: HGR-22
Name: 2-burner heavy duty gas range
Dimension: 310x770x420mm
Heat Flux: 8kw/h
Feature of HGR-22 gas range
1. With electronic ignition.
2. Equip with flame failure device.
Item No. | Description | product dimension(MM) | carton dimension(MM) | packing dimension(MM) | heat flux (KW/H) | volume (CBM) | net weight (KGS) | gross weight (KGS) |
HGR-4 | 4-burner gas range | 800× 900× 350 | 840× 740× 360 | 920× 820× 440 | 16 | 0.33 | 51 | 62 |
HGR-6 | 6-burner gas range | 1200× 900× 350 | 1240× 760× 360 | 1320× 820× 440 | 24 | 0.48 | 67 | 77 |
HGR-920 | 2-burner gas range | 400× 700× 350 | 440× 760× 420 | 440× 760× 420 | 9 | 0.14 | 30 | 40 |
HGR-940 | 4-burner gas range | 800× 900× 350 | 840× 940× 450 | 920× 1020× 530 | 18 | 0.5 | 60 | 70 |
HGR-960 | 6-burner gas range | 1200× 900× 350 | 1240× 940× 450 | 1320× 1020× 530 | 27 | 0.71 | 75 | 85 |
HGR-902 | 2-burner gas range with gas griddle | 800× 900× 410 | 850× 1000× 450 | 930× 1080× 530 | 12 | 0.53 | 60 | 70 |
HGR-904 | 4-burner gas range with gas griddle | 1200× 900× 410 | 1240x940x450 | 1320x1020x530 | 22 | 0.71 | 80 | 95 |
HGR-34 | 4-burner stove | 610× 700× 920 | 650× 760× 500 | 730× 840× 580 | 16 | 0.36 | 45 | 50 |
HGR-36 | 6-burner stove | 910× 700× 920 | 950× 760× 500 | 1030× 840× 580 | 24 | 0.5 | 65 | 70 |
HGR-38 | 8-burner stove | 1100× 700× 920 | 1250× 760× 500 | 1330× 840× 580 | 32 | 0.65 | 85 | 90 |
Item No. | Description | product dimension(MM) | carton dimension(MM) | packing dimension(MM) | heat flux (KW/H) | volume (CBM) | net weight (KGS) | gross weight (KGS) |
HGR-4 | 4-burner gas range | 800× 900× 350 | 840× 740× 360 | 920× 820× 440 | 16 | 0.33 | 51 | 62 |
HGR-6 | 6-burner gas range | 1200× 900× 350 | 1240× 760× 360 | 1320× 820× 440 | 24 | 0.48 | 67 | 77 |
HGR-920 | 2-burner gas range | 400× 700× 350 | 440× 760× 420 | 440× 760× 420 | 9 | 0.14 | 30 | 40 |
HGR-940 | 4-burner gas range | 800× 900× 350 | 840× 940× 450 | 920× 1020× 530 | 18 | 0.5 | 60 | 70 |
HGR-960 | 6-burner gas range | 1200× 900× 350 | 1240× 940× 450 | 1320× 1020× 530 | 27 | 0.71 | 75 | 85 |
HGR-902 | 2-burner gas range with gas griddle | 800× 900× 410 | 850× 1000× 450 | 930× 1080× 530 | 12 | 0.53 | 60 | 70 |
HGR-904 | 4-burner gas range with gas griddle | 1200× 900× 410 | 1240x940x450 | 1320x1020x530 | 22 | 0.71 | 80 | 95 |
HGR-34 | 4-burner stove | 610× 700× 920 | 650× 760× 500 | 730× 840× 580 | 16 | 0.36 | 45 | 50 |
HGR-36 | 6-burner stove | 910× 700× 920 | 950× 760× 500 | 1030× 840× 580 | 24 | 0.5 | 65 | 70 |
HGR-38 | 8-burner stove | 1100× 700× 920 | 1250× 760× 500 | 1330× 840× 580 | 32 | 0.65 | 85 | 90 |
